Sale!

Rocosoft PTZJoy Studio PTZ Controller

$1,699.00

PRODUCT HIGHLIGHTS

  • Convenient on-screen controls for centralized multi-camera management
  • Works on PC, Laptop, Tablet, TriCaster, vMix, Wirecast, OBS, Livestream
  • Precise control of Pan/Tilt/Zoom/Focus/Iris functions with variable speed
  • Supports all Professional and Gaming USB Joysticks, including XBox 360
  • Use one or multiple USB Joysticks to precisely control individual cameras
  • Set and recall up to 255 presets with variable preset recall speed
  • Customizable Preset Buttons – add your own graphics or custom labels
  • Multi-Camera Direct Preset Panel – control multiple cameras in one, simplified view
  • PTZPad™ Mini Visual Preset Panel – a “bird’s eye view” GUI for preset recall
  • Macros to control vMix, TriCaster, Panasonic, Blackmagic Atem switchers along with PTZ Cameras
  • Block a live camera from moving
  • Far-End Camera Control with our built-in API
  • Control cameras from external programs using Macros and HTTP requests
  • Task Scheduler – Schedule timed tasks for your cameras
  • Timeline Task Manager – Create a list of camera commands on a timeline
  • Camera Tracer – Record camera movements for replay

Rocosoft PTZJoy Studio PTZ Controller for Broadcasting Cameras

Rocosoft PTZJoy Pro PTZ Controller is a professional PTZ camera management solution that allows you to control IP PTZ cameras from any computer, tablet, laptop, TriCaster, vMix, Livestream, and other Live Production systems.

Replace the limited functionality hardware joystick controller with a more precise and powerful computer-based controller that works with any wired or wireless professional or gaming USB Joystick, has a precise virtual on-screen joystick, keyboard shortcuts, far-end camera control, OSD Menu access, advanced preset management, Macro Manager, PTZPad™ Mini Visual Preset Control Panel, Multi-Camera Direct Control Panel, camera automation tools, and more.

Rocosoft PTZJoy Pro PTZ Controller supports a variety of camera models and manufacturers and you can simultaneously control multiple brands such as Sony, Panasonic, Canon, NewTek, Hitachi, Marshall, JVC, iSmart, Birddog, Minrray, PTZOptics, Lumens, Datavideo, Huddlecam, Bolin, Aver, Telycam, Angekis, Flyan, Clevermic, Nova, Value HD, Avonic, QSC, SMTAV, and all other Broadcasting PTZ cameras.

Rocosoft PTZJoy™ Studio Controller Features view more details

  • Precise control of Pan/Tilt/Zoom/Focus/Iris functions with any USB Joystick
  • Supports all Professional and Gaming USB Joysticks, including Xbox 360 Controller
  • Assign commands to any button or directional pad on USB/Gaming Joystick
  • Simultaneous Pan, Tilt, and Zoom Joystick Control with Variable Speed
  • Connect up to 4 USB Joysticks and select which one to use as the main joystick
  • Use multiple USB Joysticks to control individual cameras simultaneously
  • 3 Slow Joystick Modes, PanOnly Mode, Soft Joystick Mode
  • Control Cameras using keyboard hotkeys
  • Smooth Camera Control with on-screen Virtual Joystick
  • Save and recall up to 255 Internal and 255 External camera presets
  • Control pan, tilt, and zoom speed during preset recall
  • 16 Camera Preset Buttons - Assign a custom label/graphic to a preset thumbnail
  • FarCam API - far-end camera control from anywhere using a USB Joystick
  • Web Remote - Control from anywhere using any device with a Web Browser
  • PTZPad Mini Visual Preset Control Panel - Visualize your environment with a bird's eye view GUI for preset recall
  • Multi-Cam Direct Control - simultaneously manage multiple cameras in one, simplified view
  • Iris, Shutter, Gain, White Balance, R-Gain, and B-Gain Monitoring and Adjustment
  • Create a list of tasks for your cameras to complete with Timeline Task Scheduler
  • Record joystick movements and play them back with Camera Tracer
  • Schedule automated tasks for your cameras to complete with Task Scheduler
  • Macro Sets with 8 Macro Buttons to control vMix, TriCaster, Panasonic switchers along with PTZ Cameras
  • Camera Control from external programs using Macros and HTTP requests, such as StreamDeck or Companion
  • Auto Pan and Preset Scan
  • Precise Pan, Tilt, Zoom, Focus Speed Monitor
  • On-Screen-Display (OSD) camera menu access
  • Tally Light, Mirror, Flip, Wiper, Camera On/Off, Focus Lock, and Backlight Function
  • Auto Pan and Preset Scan
  • Pan, Tilt, and Zoom Joystick direction flip option
  • Touch Screen Device Support
  • Start with Windows and Minimize to the Taskbar


Supported IP PTZ Cameras


  • Sony: BRC-X1000, SRG-120, SRG-300, SRG-360, BRC-X400, BRC-H800, BRC-H900, and all newer IP Cameras
  • NewTek: NDI NDIHX PTZ1, NDI PTZUHD, and all newer IP Cameras
  • Canon: Canon CR Series. Canon CR-X500, CR-N300, CR-N500, CR-X300, and all newer Canon cameras
  • Panasonic: AW-HE2, AW-HE40, AW-HE50, AW-HE60, AW-HE120, AW-HE130, AW-HE150, AW-UE70, AW-UN70, AW-HR140, AW-HE65, AW-UE4, AW-HE38, AW-HE58, AW-HE35, AW-HE48, AW-HE42, AW-HE20, AW-UE20, and all newer Panasonic IP cameras
  • Telycam: TLC-700-IP-35-4K, TLC-300-IP-12-4K, TLC-300-IP-12, TLC-300-IP-20, TLC-300-IP-5-4K
  • Aida: PTZ X20-IP, PTZ X12-IP
  • Lumens: All Lumens IP PTZ Cameras
  • iSmart: All iSmart IP cameras
  • Marshall: All Marshall IP Cameras
  • Birddog: All Birddog IP Cameras
  • Bolin: All Bolin IP Cameras
  • Angekis: All Angekis IP Cameras
  • PTZOptics: All IP cameras.
  • Minrray: All IP Cameras
  • Fla: All IP Cameras
  • Nova: All IP Cameras
  • Avonic: All IP Cameras
  • SMTAV: All IP Cameras
  • Qsc: All IP Cameras
  • Avipas: All IP Cameras
  • Clevermic: All IP Cameras
  • ValueHD: All IP Cameras
  • Datavideo: PTC-150, PTC-200, and all newer IP Cameras

Sony: BRC-X1000, BRC-300, BRC-H300, BRC-H700, BRC-Z700, BRC-H900, BRC-Z330, SNC-RZ30, EVI-H100S, EVI-H100S/W, EVI-H100V, EVI-H100V/W, EVI-HD1, EVI-HD3V, EVI-HD7, EVI-DHD7V, SRG-300H, SRG-300SE, SRG-120DH, SRG-360, PCS-HG90, PCSA-CHG90, EVI-D30, EVI-D31, EVI-D70, EVI-D80, EVI-D90, EVI-D100, EVI-D100P, EVI-D20G, BRC-X400, and all newer Sony Visca PTZ cameras
Canon: XU Series, Canon BU Series, Canon NU Series, Canon CR Series. Canon XU-80, XU-81, BU-47, BU-46, CR-X500, CR-N300, CR-N500, CR-X300, and all newer Canon cameras
Panasonic: AW-HE2, AW-HE40, AW-HE50, AW-HE60, AW-HE120, AW-HE130, AW-HE150, AW-UE70, AW-UN70, AW-HR140, AW-HE65, AW-UE4, AW-HE38, AW-HE58, AW-HE35, AW-HE48, AW-HE42, AW-HE20, AW-UE20, and all newer Panasonic IP cameras
NewTek: NDI NDIHX PTZ1, NDI PTZUHD, and all newer VISCA Serial Port controlled cameras
Vaddio: RoboShot, ClearVIEW HD-18-19-20, ClearVIEW HD-USB, PowerVIEW HD-22-30, WallVIEW HD-18-19
HuddleCam HD: 3X, 10X 720p, 10X, 3X Wide, 12X, 18X, 20X, 30X
PTZOptics: VISCA Cameras
Lumens: VC-A20P, VC-A202P, VC-G30, VC-G50, VC-200
Datavideo: PTC-120, PTC-100, PTC-150
Elmo: PTC-100s
Infocus: INF-SPTZ-2 REALCAM
Marshall: VISCA Cameras
Hitachi: VISCA Cameras
Bolin: VISCA Cameras
iSmart: VISCA Cameras
Minrray: VISCA Cameras
Ross: Pivotcam and all VISCA Cameras
Cisco/Tanberg: Precision 12x, Precision 8x, TTC8-1, TTC8-2. and other Tandberg/Cisco cameras with a serial port
1 Beyond: PTZ-S20, PTZ-IP12, PTZ-IP20, PTZ-IP30, Auto Tracker 2, AutoTracker 2 IP
All other PTZ cameras with a Mini Din8 RS-232 connector, or 9pin RS-422 Connector, or RJ45 RS-422 connector for control
Pelco: All ptz security, dome, and video conferencing cameras that use Pelco protocol
All other PTZ cameras that use Pelco protocol over RS-485 connection.

Supported Operating Systems:

  • Windows Vista
  • Windows 7
  • Windows 8
  • Windows 8.1
  • Windows 10
  • Windows 11

Supported Production Systems:

  • TriCaster Mini
  • TriCaster TC1
  • TriCaster 40
  • Tricaster 410
  • TriCaster 455
  • Tricaster 460
  • TriCaster 855
  • Tricaster 860
  • TriCaster 8000
  • TriCaster TCXD300
  • Livestream Studio HD31
  • Livestream Studio HD51
  • Livestream Studio HD510
  • Livestream Studio HD550
  • Livestream Studio HD1710
  • ALL vMix Editions
  • ALL Wirecast Editions

Supported Joysticks

All USB, bluetooth, and gaming joysticks that can be recognized by Windows OS are supported for use with Rocosoft PTZ Camera Controller Software. Here are some examples of joysticks that are supported:

  • Logitech 3D PRO
  • Logitech Attack 3
  • CH Fighterstick USB Joystick
  • CH Combatstick
  • Thrustmaster USB Flightstick
  • Thrustmaster HOTAS WARTHOG
  • CH Products USB PTZ Joystick Controller
  • AXIS Controller
  • Ipega Controller
  • Xbox Controller
  • Xbox 360 Controller
  • PS3 Controllers
  • PS4 Controllers

Support Programmable Controllers:

  • Elgato Stream Deck Mini
  • Elgato Stream Deck
  • Elgato Stream Deck XL
  • Elgato Stream Deck +
  • Xkeys - 128 Key, 24 Key, 60 Key, 80 Key, and all others


Purchasing Rocosoft PTZJoy Studio PTZ Controller


Rocosoft PTZJoy Studio PTZ Controller works with all IP PTZ cameras and controls different camera brands.

Once you purchase Rocosoft PTZJoy Studio Controller, you will receive an email with a download link and activation instructions.

With multiple versions of our PTZ Camera Controller Software, you can choose the level of control that fits your needs. Each version includes core features that are integrated across all three versions but have different feature sets tiered to varying video production setups, camera operator preferences, and technical requirements. Each version builds on the previous one, adding more features, tools, and functionality as you go. We offer upgrades from one product to the next for only the difference in price. If your camera control needs change or you need more tools down the road, you can simply upgrade to the next product up.

We are here to support you! With over 20 years in this industry, we have thousands of satisfied customers worldwide and our support is the best in the industry. Support is available for as long as you own your Rocosoft product. Please don't hesitate to reach out to us for help with your order, help with installation, or help with using our product. Contact us here.

Find the perfect level of control for YOUR setup

100% Satisfaction Guaranteed + Lifetime Support

EasyPTZ

Multi-Camera PTZ Controller Joystick Software

PTZJoy PRO

Advanced Camera Control and Preset Management

PTZJoy STUDIO

Complete Camera Automation and Control Studio

Videos

How to Control PTZ Cameras with PTZJoy

How to Set and Recall Presets with PTZJoy



Camera Automation with Timeline Task Manager Tool



Camera Automation with Camera Tracer Tool

Macro Manager - Controlling PTZ Cameras and vMix with Macros



Macro Manager - Controlling PTZ Camera and TriCaster w/ Macros

Control PTZ Cameras with an Xbox 360 Controller



PTZ Camera Control with Elgato Streamdeck and PTZJoy

Media Type

PC Download – Software Installation and Activation Instructions sent via email along with User Manual.

Licensing

1 computer per license. Purchased software does not expire. License can be transferred to a different computer.
